Inside ф

   Braid ф

 Outside  ф

Working pressure

Test pressure

Burst pressure

Bend radius

Weight

mm

dash

inch

Min

Max

Min

Max

Min

Max

bar

psi

bar

psi

bar

psi

mm

kg/m

6

-4

1/4

6.2

7.0

14.1

15.3

17.1

18.7

500

7250

1000

14500

2000

29000

150

0.64

10

-6

3/8

9.3

10.1

16.9

18.1

20.6

22.2

460

6670

920

13340

1840

26680

180

0.75

12

-8

1/2

12.3

13.5

19.4

21.0

23.8

25.4

425

6163

850

12326

1700

24650

230

0.89

16

-10

5/8

15.5

16.7

23.0

24.6

27.4

29.0

400

5800

800

11600

1600

23200

250

1.10

19

-12

3/4

18.6

19.8

27.4

29.0

31.4

33.0

380

5510

760

11020

1520

22040

300

1.50

25

-16

 1

25.0

26.4

34.5

36.1

38.5

40.9

320

4640

640

9280

1280

18560

340

2.00

31

-20

 1-1/4

31.4

33.0

45.0

47.0

49.2

52.4

210

3045

420

6090

840

12180

460

3.00

38

-24

 1-1/2

37.7

39.3

51.4

53.4

55.6

58.8

185

2680

370

5365

740

10730

560

3.40

51

-32

 2

50.4

52

64.3

66.3

68.2

71.4

175

2538

350

5076

700

10150

660

4.35
