Inside ф

Braid ф

Outside  ф

Working pressure

Test pressure

Burst pressure

Bend radius

Weight

mm

dash

inch

Min

Max

Min

Max

Max

bar

psi

bar

psi

bar

psi

mm

kg/m

5

-3

3/16

 4.6

5.4

10.6

11.6

14.1

415

6020

830

12035

1650

23925

90

0.32

6

-4

1/4

6.2

7.0

12.1

13.3

15.7

400

5800

800

11600

1600

23200

100

0.36

8

-5

5/16

7.7

8.5

13.7

14.9

17.3

350

5075

700

10150

1400

20300

115

0.45

10

-6

3/8

9.3

10.1

16.1

17.3

19.7

330

4785

660

9570

1320

19140

130

0.54

12

-8

1/2

12.3

13.5

19.0

20.6

23.0

275

3990

550

7975

1100

15950

180

0.68

16

-10

5/8

15.5

16.7

22.2

23.8

26.2

250

3625

500

7250

1000

14500

200

0.80

19

-12

3/4

18.6

19.8

26.2

27.8

30.1

215

3120

430

6235

850

12325

240

0.94

25

-16

 1

25.0

26.4

34.1

35.7

38.9

165

2390

330

4785

660

9570

300

1.35

31

-20

 1-1/4

31.4

33.0

43.3

45.7

49.5

125

1810

250

3625

500

7250

420

2.15

38

-24

 1-1/2

37.7

39.3

49.6

52.0

55.9

90

1305

180

2610

360

5220

500

2.65

51

-32

 2

50.4

52

62.3

64.7

68.6

80

1160

160

2320

320

4640

630

3.42
