Inside ф

  Outside  ф

Working pressure

Test pressure

Burst pressure

Bend radius

Weight

mm

dash

inch

Min

Max

Min

Max

bar

psi

bar

psi

bar

psi

mm

kg/m

5

-4

3/16

4.8

5.5

12.7

13.7

210

3045

420

6090

840

12180

75

0.24

6.3

-5

1/4

6.4

7.2

14.3

15.3

210

3045

420

6090

840

12180

85

0.28

8

-6

5/16

7.9

8.7

16.7

17.6

157

2270

315

4570

630

9135

100

0.35

11

-8

13/32

10.3

11.1

18.9

20.0

140

2030

280

4060

560

8120

115

0.38

12.5

-10

1/2

12.7

13.7

22.8

24.0

122

1770

245

3550

490

7105

140

0.51

16

-12

5/8

15.9

17.0

26.8

28.0

105

1520

210

3045

420

6090

165

0.68

22

-16

7/8

22.2

23.3

30.6

32.2

56

810

112

1620

224

3250

185

0.70

29

-20

 1-1/8

28.6

29.8

37.3

38.9

43

620

86

1260

175

2540

230

0.80

35

-24

 1-3/8

34.9

36.1

43.7

45.2

35

510

70

1015

140

2030

265

0.93

46

-32

1-13/16

46.0

47.2

55.2

57.6

24

350

49

700

98

1420

335

1.32

60

-40

2-3/8

60.3

61.9

71.8

74.2

24

350

49

700

98

1420

610

2.96

76

-48

3

76.2

77.8

89.3

91.7

14

200

28

410

56

810

840

4.10
